- Extra capacity by side washsystem: capacity up to 8 GN-trays 1/1 or 5 EN2 container
- Detergent direct spraying system: system soaks the wash ware following the detergent pre-washing cycle and softens even the most severely encrusted food residues
- VISIOTRONIC control: single-button control with remaining time indicator together with text and graphic display
- SENSO-ACTIVE resource management: constantly measures the quality of the wash water and keeps the amount of rinsing needed in each rinse cycle to the minimum in order to guarantee a fully hygienic wash result
- POWER wash: high-pressure washing to wash heavily soiled wash items
- CLIP-IN wash and rinse arms: wash and rinse arms can be removed with one hand and without any tools
- USB-interface: comfortable download of operational data in form of a protocol via USB
- GENIUS-X² fine filter system: advanced filter system with prewash function reduces detergent consumption up to 35 %
- ROTOR-X wash system: separate rotating upper and lower 4-spoke wash arms deliver dynamic wash power
- VAPOSTOP (optional): prevents vapour to escape from machine when door is opened
- The optional drain heat recovery transfers heat from hot drain water to the fresh-water supply, saving up to 12.9 kW
- The optional exhaust heat recovery uses steam to heat fresh feed water and reduces the amount of power needed, saving up to 7.8 kW
- Loading height: above-average loading height of 860 mm
- Intelligent energy management: the available energy is used continuously. Thus, at a low total loading value the heating time gets reduced
- VAPO-ACTIVE steam washing: significantly less manual pre-cleaning and second runs by intensive wash cycles with steam injection
- Interlocked strainer: prevents operation without tank strainer
- EASY-CLEAN concept: blue markings in the machine help the operator to identify the components which require cleaning
- Hygiene programme: for removal of calcium carbonate and other deposits from wash chamber
- Front door utensil washer
- Useable inside dimensions w x d x h: 1110 x 773 x 825mm
- Nominal capacity up to 30 cycles/h
- 6 automatic programmes: short, standard, steam washing, detergent direct spraying, continuous, hygiene
- Double walled housing
- Strainer soil sensor
- Refill signal (detergent / rinse aid)
- Self-cleaning programme
- Separate tank fill (can be deactivated)
- Ready to install - completely equipped: fill / drain hose, electrical cable, detergent dispenser, rinse aid dispenser, rinse pump, drain pump, back-flow preventer, tank heating, separate tank fill (can be deactivated), back panel
- Tank, frame, wash / rinse arms and panels are stainless steel 1.4301
VARIANTS
Order number |
Description |
UPT-10A |
Basic model AC 400/50/3N Please note: Racks need to be ordered separately
|
TECHNICAL DATA
Cylce times* |
120 / 240 / 280 sec. and special cycles |
Water consumption |
14 l/rack |
Tank capacity |
130 l |
Tank heating |
6.1 kW |
Power supply |
400 / 50 / 3N |
Booster loading - Standard |
18.1 kW |
Booster loading - Alternative |
9.1 kW |
Total loading - Standard |
24.5 kW / 3 x 50 A |
Total loading - Alternative |
18.5 kW / 3 x 32 A |
Wash pump |
2 x 2.9 kW | 2 x 1,150 l/min |
Rack size |
1,240 x 700 mm |
Loading height |
860 mm |
Noise level |
70 dB (A) |
Weight (gross / net) |
325 / 305 kg |
*Thermostop guarantees required temperatures with cold water connection, the actual cycle times extend accordingly.
ACCESSORIES
Order number |
Description |
SEF-15/075 |
Integrated drain heat recovery alternatively with reduced kW booster heater (specify full kW for high capacity throughput – reduced kW may allow reduced total loading)
|
SEF-15/074 |
Integrated exhaust heat recovery, condensation and VAPOSTOP system
|
ML71620 |
Rack assortment UXT/UPT: base rack 323741, universal insert 323753, cutlery rack C-01-07
|
ML71655 |
Rack assortment UXT/UPT: base rack 323741, insert 323637 for 8 large sheets, cutlery rack C-01-07
|
323741 |
Basic rack 1,240 x 700 mm, for UXT/UPT Models
|
323637 |
Insert 568 x 625 mm, for 8 large sheets, distance between rows: 5.9 cm
|
323753 |
Insert 568 x 665 mm suitable for plates, bowls, sheets, etc.
|
HLSU-1 |
Only available in Germany
|
